NL6448BC33-54 LCD Module

Name: NL6448BC33-54 LCD Module
Brand: Sun Tech Services
Price: 11650 INR
Availability: InStock

Price 11650 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

NL6448BC33-54 LCD Module Specification

Input
Digital (RGB parallel), Timing signal

Interface
RGB Parallel, CMOS

Display Type
TFT-LCD

Power Source
External DC Power

Components
TFT LCD Panel, Driver IC, LED Backlight

Response Time
16 ms (typical)

Power Supply
DC Power Supply

Resolution
640 (RGB) x 480 (VGA)

Usage
Industrial / Medical

Features
LED Backlight, Wide Temperature Range, High Contrast

Operating Temperature
-20C to +70C

Product Type
NL6448BC33-54 LCD Module

Application
Industrial / Medical

Rated Voltage
3.3 V (Logic), 12 V (Backlight)

Supply Voltage
3.3 VDC (Logic)

Size
8.4 inch

Dimension (L*W*H)
199.5 mm x 149.0 mm x 14.0 mm

Function
Display visual data for industrial equipment

Color
Sliver

Weight
Approx. 350g

Warranty
Yes

Current Rating
Backlight: 350 mA (typical), Logic: 200 mA

Thickness
Approx. 14 mm

Frequency
60 Hz (frame rate)

Contrast Ratio
600:1 (typical)

Viewing Angle
65/65/45/65 (Left/Right/Up/Down)

Connector Type
30-pin FFC/FPC

Number of Colors
262K (18-bit)

Active Area
170.88 mm (H) 128.16 mm (V)

Storage Temperature
-30C to +80C

Pixel Pitch
0.264 mm (H) x 0.264 mm (V)

Signal Type
TTL

Brightness
350 cd/m2 (typical)

Backlight Type
LED

Mounting Type
Panel Mount

RoHS Compliant
Yes

NL6448BC33-54 LCD Module Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
7 Days

About NL6448BC33-54 LCD Module

The NL6448BC33-54 LCD Module stands out as a cost-effective display solution, favored for its robust performance and versatile application range. Garnering favorable reviews, this preeminent 8.4-inch TFT-LCD is featured for its radiant 350 cd/m2 brightness, spectacular 600:1 contrast, and wide 262K color support. With panel mount design, industrial-grade reliability, and RoHS compliance, it is ideal for both industrial and medical use. Its wide viewing angles, high response speed, and LED backlight deliver consistent, high-quality visuals, ensuring dependable operation for professional environments.

Versatile Usage: Serving Multiple Applications

The NL6448BC33-54 LCD Module excels in diverse industrial and medical settings. It is widely used by OEMs, manufacturers, and integrators for equipment requiring reliable data display. With its easy panel mount and standard RGB parallel interface, direction of use is straightforward: simply integrate with compatible industrial controllers for instant deployment. This module's radiant visuals and robust construction make it suitable for control panels, diagnostic devices, and monitoring systems in various demanding environments.

Efficient Delivery & Domestic Market Presence

Our logistics network ensures timely delivery of the NL6448BC33-54 LCD Module across the main domestic market in India. Packaging is handled with utmost care, utilizing anti-static materials and shock-absorbing solutions to safeguard the module during transit. Competitive list price and prompt delivery commitments further enhance client satisfaction. As a leading distributor, importer, supplier, and service provider, we guarantee reliable support and seamless fulfillment for all industrial and medical customers.

FAQ's of NL6448BC33-54 LCD Module:

Q: How do I integrate the NL6448BC33-54 LCD Module into my industrial equipment?

A: The NL6448BC33-54 can be integrated by connecting its 30-pin FFC/FPC connector to your controller's RGB parallel (TTL) interface and powering it with the specified DC supply. Secure it using the panel mount design for stability.

Q: What are the primary benefits of using this LCD module in medical and industrial applications?

A: Its high brightness, wide viewing angles, rapid response time, and robust temperature tolerance ensure clear and reliable visual data display essential for precise operations in demanding environments.

Q: When can I expect delivery after placing an order within India?

A: Delivery timelines typically range from a few days to a week, depending on your location and current logistics conditions. We prioritize prompt dispatch to support your project timelines.

Q: Where is the NL6448BC33-54 LCD Module primarily used?

A: This display finds application mainly in industrial control systems and medical diagnostic equipment, but it is also suitable for other professional environments requiring high-quality visual data presentation.

Q: What packaging measures are taken to ensure the module's safety during shipping?

A: Each module is carefully packaged using anti-static shielding and shock-absorbent materials to prevent any damage during transit, ensuring it arrives in pristine working condition.
